| Generelt |
| Enhedstype | Netværksadapter |
| Model | Indstikskort |
| Grænseflade (bus) type | PCI Express 3.0 x8 |
| PCI-specifikationsrevision | PCIe 3.0 |
| Netværk |
| Porte | Gigabit Ethernet / 10Gb Ethernet / 25Gb Ethernet SFP28 x 2 |
| Forbindelsesteknologi | Kablet |
| Dataforbindelsesprotokol | Gigabit Ethernet, 10 Gigabit Ethernet, 25 Gigabit Ethernet, RDMA over Converged Ethernet (RoCE v1), RDMA over Converged Ethernet (RoCE v2) |
| Dataoverførselshastighed | 25 Gbps |
| Egenskaber | IPv6 understøttet, IPv4 support, RSS, UEFI support, SR-IOV, VXLAN, NVGRE, sikkerhedsstøvle, NPAR, Mware NetQueue and Microsoft VMQ, DPDK, firmware tillidsrod, revisionslogge, tunnel-offload, GENEVE support, desinficering, UEFI PXE Boot, legacy BIOS PXE Boot |
| Processor / Hukommelse |
| Processor | 1 x Broadcom BCM57414 |
| Ekspansion / Konnektivitet |
| Interface | 2 x 1Gb Ethernet/10Gb Ethernet/25Gb Ethernet - SFP28 |
| Effekt |
| Strømforbrug ved drift | 9.1 Watt |
| Oplysninger om kompatibilitet |
| Designet for | HPE Nimble Storage dHCI Medium Solution with HPE ProLiant DL325 Gen10 Plus
HPE ProLiant DL110 Gen10 Plus Front Cabled Telco, DL20 Gen10 Plus, DL20 Gen10 Plus Base, DL20 Gen10 Plus Entry, DL20 Gen10 Plus High Performance, DL20 Gen10 Plus Performance, DL325 Gen10 Plus, DL325 Gen10 Plus All-NVMe Flash Node for Qumulo, DL325 Gen10 Plus All-NVMe Flash Node for Software Defined Storage, DL325 Gen10 Plus for Weka BAse Tracking, DL325 Gen10 Plus for Weka Expansion Tracking, DL325 Gen10 Plus V2, DL325 Gen10 Plus V2 Base, DL325 Gen10 Plus V2 for Weka Base Tracking, DL325 Gen10 Plus V2 Performance, DL345 Gen10 Plus Base, DL360 Gen10 Plus, DL360 Gen10 Plus All-NVMe Server for Software Defined Storage, DL365 Gen10 Plus, DL380 Gen10 Plus, DL380 Gen10 Plus Network Choice, DL385 Gen10 Plus, DL385 Gen10 Plus Entry, ML30 Gen10 Plus, ML30 Gen10 Plus Entry, ML30 Gen10 Plus Performance, XL220n Gen10 Plus, XL225n Gen10 Plus 1U Node, XL290n Gen10 Plus |
|
