| Generelt |
| Enhedstype | Netværksadapter |
| Model | Indstikskort - lavprofil |
| Grænseflade (bus) type | PCI Express 3.0 x8 / PCI Express 3.0 x4 |
| PCI-specifikationsrevision | PCIe 3.0 |
| Netværk |
| Porte | 25 Gigabit Ethernet x 2 |
| Forbindelsesteknologi | Kablet |
| Dataforbindelsesprotokol | 10 Gigabit Ethernet, 25 Gigabit Ethernet |
| Dataoverførselshastighed | 25 Gbps |
| Præstation | Dobbeltretnings-gennemløb: 100 Gbps
Båndbredde pr. port: 50 Gbps |
| Kapacitet | Jumbo-rammestørrelse: op til 9,6 KB |
| Protokol til fjernadministration | SNMP |
| Statusindikatorer | Link/aktivitet |
| Egenskaber | VLAN-understøttet, IPv6 understøttet, fuld dupleksmodus, TCP/IP offloading, QoS, Jumbo Frames support, IPv4 support, PXE support, LACP support, LLDP support, LSO, RSS, UEFI support, TSO, QoS-markering, MSI-X, UDP/IP-offloading, TCP/IP checksum offload, RoCE, VXLAN, NVGRE, RoCE v2 |
| Overensstemmelsesstandarder | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.1ab (LLDP), IEEE 802.3az, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qau, IEEE 802.1Qbg, IEEE 1588v2 |
| Processor / Hukommelse |
| Processor | 1 x Mellanox Technologies Mellanox ConnectX-4 Lx |
| Ekspansion / Konnektivitet |
| Interface | 2 x 25Gb Ethernet - SFP28 |
| Diverse |
| Overensstemmelsesstandarder | FCC Klasse A certificeret, CISPR 22 Klasse A, ICES-003, EN55024, EN 60950-1, RoHS, ACA, cTUVus, BSMI Class A, VCCI Class A, EN 55022 Class A |
| Effekt |
| Strømforbrug ved drift | 9.7 Watt |
| Programmer / Systemkrav |
| OS nødvendig | SuSE Linux Enterprise Server 11, Microsoft Windows Server 2012, Oracle Solaris 11.1, Microsoft Windows Server 2012 R2, VMware ESXi 5.5, Ubuntu 14.04, Red Hat Enterprise Linux 7, Red Hat Enterprise Linux 6.6, Red Hat Enterprise Linux 7.1, Citrix XenServer 6.5, SuSE Linux Enterprise Server 12, Red Hat Enterprise Linux 6.7, Red Hat Enterprise Linux 7.2, VMware ESXi 6.0 |
| Producentgaranti |
| Service & Support | Begrænset garanti - 1 år |
| Miljømæssige parametre |
| Min. driftstemperatur | 5 °C |
| Maks. driftstemperatur | 60 °C |
| Fugtighedsgrad ved brug | 5 - 95 % (ikke-kondenserende) |
| Oplysninger om kompatibilitet |
| Designet for | HPE Apollo 20 2U Node, 4200 Gen10, 4200 Gen10 336TB Archive Node with 25Gb NIC for Qumulo, 4200 Gen10 for HPE Ezmeral Container Platform, 4200 Gen10 for HPE Ezmeral Tracking, 4200 Gen10 Qumulo Archive Node, 4200 Gen10 Qumulo Hybrid Node, 4200 Gen9 for Google
HPE Edgeline e920, e920d
HPE Nimble Storage dHCI Large Solution with HPE ProLiant DL380 Gen10, Medium Solution with HPE ProLiant DL360 Gen10, Small Solution with HPE ProLiant DL360 Gen10
HPE ProLiant DL180 Gen10 Entry, DL180 Gen10 SMB, DL325 Gen10 Base, DL325 Gen10 Solution, DL360 Gen10 All Flash Server for Weka, DL360 Gen10 Compute Server for Cohesity DataPlatform, DL360 Gen10 Low, DL360 Gen10 Network Choice, DL360 Gen10 Performance for Cohesity DataPlatform, DL360 Gen10 SMB, DL360 Gen10 SMB Network Choice, DL360 Gen10 Solution, DL360 Gen9 High Performance, DL380 Gen10 All Flash Server for Datera, DL380 Gen10 Entry SMB, DL380 Gen10 for Cohesity DataPlatform, DL380 Gen10 for SAP HANA Compute Block, DL380 Gen10 Hybrid Server for Datera, DL380 Gen10 Network Choice, DL380 Gen10 Network Choice for CTERA, DL380 Gen10 NVMe All Flash Server for Datera, DL380 Gen10 Server for CTERA, DL380 Gen10 SMB, DL380 Gen10 SMB Networking Choice, DL380 Gen10 Solution, DL388 Gen10 Network Choice, DL560 Gen10 for SAP HANA Compute Block, DL580 Gen9 SAP HANA Scale-out Base Configuration, DL580 Gen9 SAP HANA Scale-up Base Configuration, DX380 Gen10, DX560 Gen10, ML350 Gen10 High Performance, ML350 Gen10 SMB, ML350 Gen10 Solution, ML350 Gen10 Special Server, XL170r Gen10 24TB Server for Cohesity DataPlatform, XL170r Gen10 36TB Add-on Server for Cohesity DataPlatform, XL170r Gen10 Server for BlueData EPIC, XL190r Gen10 for HPE Ezmeral Container Platform, XL270d Gen10 for HPE Ezmeral Container Platform, XL450 Gen10
HPE SimpliVity 325 Gen10 Node, 380 Gen10 G Node, 380 Gen10 H Node, 380 Gen10 Network Choice G Node, 380 Gen10 Network Choice H Node
HPE StoreEasy 1660 Expanded Storage |
|
